Rolex Sydney to Hobart Yacht Race.  https://rolexsydneyhobart.com

Radios & Installation.

Boats shall be capable of transmitting/
receiving, as a minimum, on the following
frequencies:-


• VHF - International Channels 16, 72, 73, 80 and 81


• HF/SSB - 4483kHz and 6516kHz


and such other frequencies as the
Organising Authority may determine


Emergency aerials are required to have
their mounting brackets and cabling
permanently installed.


Boats shall provide a Radio Inspection
Certificate with the entry form where a current
certificate is not already held by the
Organising Authority. The Radio Inspection
Certificate is to be completed by an accredited
radio technician to verify the adequacy
of the installation and operation of the radios.
A boat in the Cruising Division that does not
have an HF/SSB may seek a dispensation
from the Race Committee by demonstrating
that it has another satisfactory method of
contacting the Organising Authority, such
as by satphone or by email via SATCOM C,
D+ or other system.
Pre-race radio check
Boats shall carry out a radio check on 4483
and 6516kHz between 15 December
2009 and 22 December 2009 with an
organisation to be advised to entrants at a
later date.


The organisation conducting the radio
checks will monitor these frequencies
between 0800 hours and 1800 hours
during that period. Radio checks will not be
approved outside of these hours.
Boats not recorded as having adequate
radio signal strength will not be eligible to
start.


Operation
Boats shall maintain a 24 hour listening
watch for the duration of their race on VHF
Channel 16.
For radio communications, a boat’s name
may be limited to not more than two words.
The Race Committee may alter names
where appropriate.
The Sailing Instructions will require that
boats report by radio when they are in
the vicinity of Green Cape and make a
declaration confirming their time of passing
as well as the following:
• The HF radio is operational
• Liferaft(s) are on board
• Engine and batteries are operational
• Boat and crew are in a satisfactory
condition to continue
• The skipper has comprehensively
considered the most current weather
forecast and the boat and crew are fully
prepared for the conditions forecast.
Boats which are not recorded as having
met the reporting requirements above shall
be disqualified without a hearing (amends
RRS 63.1).
Boats that make a false report will be
subject to action by the Race Committee in
accordance with RRS 60.2(c).

The frequencies used for marine communications are internationaly agreed by the International Telecommunication Union (ITU). Below you will find a list of HF frequencies. In the main most frequencies are Duplex and intended for ship to shore use. Some bands do have simplex channels which can be used for either ship to shore or intership working.

Marine Distress Frequencies (Radio Telephone (R/T) & DSC)

Band R/T Frequency DSC Frequency Day Time Range Night Time Range
MF 2182 kHz 2187.5 kHz 150 nm 500 nm
HF4 4125 kHz 4207.5 kHZ 300 nm 1000 nm
HF6 6215 kHz 6312 kHz 600 nm 1500 nm
HF8 8291 kHz 8414.5 kHZ 1000 nm 2000 nm
HF12 12290 kHz 12577 kHz 2500 nm
HF16 16420 kHz 16804.5 kHz
VHF 156.800 MHz (Ch16) 156.525 MHz (Ch 70) 30 nm 30 nm

NOTE: Range is for guidance only and will depending on your operating conditions.
4 MHz simplex ship to ship HF frequencies, shared with fixed services C-1

4000 kHz 40003 kHz 40006 kHz 4009 kHz 4012 kHz 4015 kHz 4018 kHz
4021 kHz 4024 kHz 4027 kHz 4030 kHz 4033 kHz 4036 kHz 4039 kHz
4042 kHz 4045 kHz 4048 kHz 4051 kHz 4054 kHz 4057 kHz 4060 kHz
8 MHz simplex ship to ship HF frequencies, shared with fixed services C-2
8101 kHz 8104kHz 8107 kHz 8110 kHz 8113 kHz 8116 kHz 8119 kHz
8122 kHz 8125 kHz 8128kHz 8131 kHz 8134 kHz 8137 kHz 8140 kHz
8143 kHz 8146 kHz 8149 kHz 8152 kHz 8155 kHz 8158 kHz 8161 kHz
8164 kHz 8167 kHz 8170 kHz 8173 KHz 8176 kHz 8179 kHz 8182 kHz
8185 kHz 8188 kHz 8191 kHz
Primary HF ship to ship frequencies
ID 2 MHz 4 MHz 6 MHz 8 MHz 12 MHz 16 MHz 18 MHz 22 MHz 25 MHz
A 2065.0 kHz 4146 kHz 6224 khz 8294 kHz 12353 kHz 16528 kHz 18825 kHz 22159 kHz 25100 kHz
B 2079.0 kHz 4149 kHz 6227 kHz 8297 kHz 12356 kHz 16531 kHz 18828 kHz 22162 kHz 25103 kHz
C 2093.0 kHz   6230 kHz   12359 kHz 16534 kHz 18831 kHz 22165 kHz 25106 kHz
D 2096.5 kHz       12362 kHz 16537 kHz 18834 kHz 22168 kHz 25109 kHz
E 2214.0 kHz       12365 kHz 16540 kHz 18837 kHz 22171 kHz 25112 kHz
F           16543 kHz 18840 kHz 22174 kHz 25115 kHz
G           16546 kHz 18843 kHz 22177 kHz 25118 kHz
